In our last post we introduced a fictional example of Squirrel, Oppy, and Acme learning to use SLSA and covered the basics of what their implementations might look like. Today we’ll cover the details: where to store attestations and policies, what policies should check, and how to handle key distribution and trust.

Attestation storage

Attestations play a large role in SLSA and it’s essential that consumers of artifacts know where to find the attestations for those artifacts.

Recording & verifying dependencies

Acme wants to record and verify the dependencies that go into its container into the SLSA provenance. Acme would prefer that this functionality were just built-in their build service, but that feature isn’t available yet. Instead they’ll need to do something themselves. They have a few options at their disposal:

Proxied verification

Acme considered creating a proxy for their existing builder to proxy outbound connections. This proxy could verify everything fetched and use its logs to populate the provenance. Since this proxy is trusted it would be easier to meet “non-falsifiable” requirement. Unfortunately it’s also a lot of work for Acme so they’re going to defer this idea for now.

Next time

In the first two parts of this series, we’ve covered the basics of getting started with SLSA and the details of policy and provenance storage, policy verification, and key handling. In our next post we’ll cover how Squirrel, Oppy, and Acme put this all together to protect a heterogeneous supply chain.

Basics

In order to SLSA, Squirrel, Oppy, and Acme will all need SLSA capable build services. Squirrel wants to give their maintainers wide latitude to pick a builder service of their own. To support this, Squirrel will qualify some build services at specific SLSA levels (meaning they can produce artifacts up to that level). To start, Squirrel plans to qualify GitHub Actions using an approach like this, and hopes it can achieve SLSA 4 (pending the result of an independent audit). They’re also willing to qualify other build services as needed. Oppy on the other hand, doesn’t need to support arbitrary build services. They plan to have everyone use their Autobuilder network which they hope to qualify at SLSA 4 (they’ll conduct the audit/certification themselves). Finally, Acme plans to use Google Cloud Build which they’ll self-certify at SLSA 4 (pending the result of a Google-conducted audit).

Squirrel, Oppy, and Acme will follow a similar qualification process for the source control systems they plan to support.

Verification options

Full verification

At some point, one or more of the organizations will need to do full verification of each artifact to determine if it is acceptable for a given use case. This is accomplished by checking if the artifact meets the appropriate policy.

Typically, full verification would take place with SLSA provenance, source attestations, and perhaps other specialized attestations (like vulnerability scan results). While having to coordinate this data for all of its dependencies seems like a lot of work to Acme, they’re prepared to do full verification if Squirrel and Oppy are unable to.

Delegated verification

When Acme isn’t using full verification, they can instead use delegated verification where they check if an artifact is acceptable for a use case by checking if some other trusted party who performed a full verification (such as Squirrel or Oppy) believes the artifact is acceptable.

Delegated verification is easier to perform quickly with limited data and network connectivity. It may also be easier for some users who value if someone they trust verified the artifact is good.

Squirrel likes how easy delegated verification would make things for their users and plans to support it by creating a Verification Summary Attestation (VSA) when they perform full verification.

When to verify

Verification (full or delegated) could happen at a number of different times.

On import to repo

Squirrel plans to perform full verification when an artifact is published to their repo. This will ensure that packages in the repo have met their corresponding policy. It’s also helpful because all the required data can be gathered when latency isn’t critical.

If this were the only time verification is performed, it would put the repository’s storage in the trusted computing base (TCB) of its users. Squirrel’s plans to use delegated verification (and issue VSAs) can prevent this. The signature on the VSA will prevent the artifacts from being tampered with while sitting in storage, even if they’re just SLSA 0. Downstream users will just need to verify the VSA.

Acme also wants to do some sort of verification on the import to their internal repo since it simplifies their security story. They’re not quite sure what this will look like yet.

On install

Acme also wants to do verification when an artifact is actually installed since it can remove a number of intermediaries from their TCB (their repo, the network, upstream storage systems).

If they perform full verification at install then they must gather all the required information. That could be a lot of data, but it might be simplified by gathering the data from external sources and caching it in their internal repo. A larger problem is that it requires Acme to have established trust in all parties that produced that information (e.g. every builder of every package). For a complex supply chain that may be difficult.

If Acme performs delegated verification, they only need the VSA for the packages being installed and to explicitly trust a handful of parties. This allows the complex full verification to be performed once while allowing all users of that package to perform a much simpler operation.

Given these tradeoffs Acme prefers delegated verification at install time. Squirrel also really likes the idea and plans to build install time verification directly into the Squirrel tool.

Verification could also take place each time an artifact is actually used. In this model, latency and reliability are very important (a sudden increase in site traffic may necessitate a scaling operation launching many new jobs).

Time of use verification allows the most context with which decisions can be made (“is this job allowed to run this code and is it free from vulns right now?”). It also allows policy changes to affect already built & installed software (which may or may not be desirable).

Acme wants their users to be able to verify on use without too many dependencies so they plan to provide VSAs users can use to perform delegated verification when they start the container (perhaps using something like Kyverno).

How to handle artifacts without provenance?

Inevitably a build or system may require that an artifact without ‘original’ provenance is used. In these cases it may be desirable for the importer to generate provenance that details where it got this artifact. For example, this generated provenance shows that http://example.com/foo.tgz with sha256:abc was imported by ‘auto-importer’:

Such an artifact would likely not be accepted at higher SLSA levels, but the provenance can be used to: 1) prevent tampering with the artifact after it’s been imported and 2) be a data point for future analysis (e.g. should we prioritize asking for foo.tgz to be distributed with native SLSA provenance?).

Acme might be interested in taking this approach at some point, but they don’t need it at the moment.

Next time

In our next post we’ll cover specific approaches that can be used to answer questions like “where should attestations and policies be stored?” and “how do I trust the attestations that I receive?”

Provenance

SLSA (“Supply-chain Levels for Software Artifacts”) is a framework to help improve the integrity of your project throughout its development cycle, allowing consumers to trace the final piece of software you release all the way back to the source. Achieving a high SLSA level helps to improve the trust that your artifacts are what you say they are.

This blog post focuses on build provenance, which gives users important information about the build: who performed the release process? Was the build artifact protected against malicious tampering? Source provenance describes how the source code was protected, which we’ll cover in future blog posts, so stay tuned.

Go prototype to generate non-forgeable build provenance

To create tamperless evidence of the build and allow consumer verification, you need to:

1. Isolate the provenance generation from the build process;
2. Isolate against maintainers interfering in the workflow;
3. Provide a mechanism to identify the builder during provenance verification.

The full isolation described in the first two points allows consumers to trust that the provenance was faithfully recorded; entities that provide this guarantee are called trusted builders.

Our Go prototype solves all three challenges. It also includes running the build inside the trusted builder, which provides a strong guarantee that the build achieves SLSA 3’s ephemeral and isolated requirement.

How does it work?

The following steps create the trusted builder that is necessary to generate provenance in isolation from the build and maintainer’s interference.

Step One: Create a reusable workflow on GitHub runners

Leveraging GitHub’s reusable workflows provides the isolation mechanism from both maintainers’ caller workflows and from the build process. Within the workflow, Github Actions creates fresh instances of virtual machines (VMs), called runners, for each job. These separate VMs give the necessary isolation for a trusted builder, so that different VMs compile the project and generate and sign the SLSA provenance (see diagram below).

Running the workflow on GitHub-hosted runners gives the guarantee that the code run is in fact the intended workflow, which self-hosted runners do not. This prototype relies on GitHub to run the exact code defined in the workflow.

The reusable workflow also protects against possible interference from maintainers, who could otherwise try to define the workflow in a way that interferes with the builder. The only way to interact with a reusable workflow is through the input parameters it exposes to the calling workflow, which stops maintainers from altering information via environment variables, steps, services and defaults.

To protect against the possibility of one job (e.g. the build step) tampering with the other artifacts used by another job (the provenance step), this approach uses a trusted channel to protect the integrity of the data. We use job outputs to send hashes (due to size limitations) and then use the hashes to verify the binary received via the untrusted artifact registry.

Step 2: Use OpenID Connect (OIDC) to prove the identity of the workflow to an external service (Sigstore)

OpenID Connect (OIDC) is a standard used across the web for identity providers (e.g., Google) to attest to the identity of a user for a third party. GitHub now supports OIDC in their workflows. Each time a workflow is run, a runner can mint a unique JWT token from GitHub’s OIDC provider. The token contains verifiable information of the workflow identity, including the caller repository, commit hash, trigger, and the current (reuseable) workflow path and reference.

Using OIDC, the workflow proves its identity to Sigstore’s Fulcio root Certificate Authority, which acts as an external verification service. Fulcio signs a short-lived certificate attesting to an ephemeral signing key generated in the runner and tying it to the workload identity. A record of signing the provenance is kept in Sigstore’s transparency log Rekor. Users can use the signing certificate as a trust anchor to verify that the provenance was authenticated and non-forgeable; it must have been created inside the trusted builder.

Verification

The consumer can verify the artifact and its signed provenance with these steps:

1. Look up the corresponding Rekor log entry and verify the signature;
2. Verify the trusted builder identity by extracting it from the signing certificate;
3. Check that the provenance information matches the expected source and build.

See an example in action in the official repository.

Performing these steps guarantees to the consumer that the binary was produced in the trusted builder at a given commit hash attested to in the provenance. They can trust that the information in the provenance was non-forgeable, allowing them to trust the build “recipe” and trace their artifact verifiably back to the source.

Extra Bonus: Keyless signing

One extra benefit of this method is that maintainers don’t need to manage or distribute cryptographic keys for signing, avoiding the notoriously difficult problem of key management. The OIDC protocol requires no hardcoded, long-term secrets be stored in GitHub’s secrets, which sidesteps the potential problem of key mismanagement invalidating the SLSA provenance. Consumers simply use OIDC to verify that the binary artifact was built from a trusted builder that produced the expected provenance.

Next Steps

Utilizing the SLSA framework is a proven way for ensuring software supply-chain integrity at scale. This prototype shows that achieving high SLSA levels is easier than ever thanks to the newest features of popular CI/CD systems and open-source tooling. Increased adoption of tamper-safe (SLSA 3+) build services will contribute to a stronger open-source ecosystem and help close one easily exploited gap in the current supply chain.

We encourage testing and adoption and welcome any improvements to the project. Please share feedback, comments and suggestions at slsa-github-generator-go and slsa-verifier project repositories. We will officially release v1 in a few weeks!

In follow-up posts, we will demonstrate adding non-forgeable source provenance attesting to secure repository settings, and showcase the same techniques for other build toolchains and package managers, etc. Stay tuned!

We are paying higher rewards retroactively for eligible Google Nest and Fitbit devices reports submitted in 2021. And, starting today, for the next six months, will double the reward amount for all new eligible reports applicable to Google Nest & Fitbit devices in scope.

We will continue to take reports on our web applications, services, and mobile apps at their existing reward levels. Please keep those coming!

An enhanced rewards program

Building on our previous programs to improve devices’ embedded security posture, we’re bringing all our first-party devices under a single program, starting with Google Nest, Fitbit, and Pixel.
This program extends the Android Security Reward Program, making it easier for researchers to submit a vulnerability in first-party devices and improving consistency across our severity assignments. Refer to the Android and Google Devices Security Reward Program for more details.

What interests us?

We encourage researchers to report firmware, system software, and hardware vulnerabilities. Our wide diversity of platforms provides researchers with a smorgasbord of environments to explore.

What’s next?

We will be at the Hardwear.io conference this year! The VRP team is looking forward to meeting our security peers in person. We’ll be talking about the architecture of a couple of our devices, hoping to give security researchers a head start in finding vulnerabilities. We’ll have plenty of swag, too!

We will continue to enhance the researchers’ experience and participation. We intend to add training documentations and target areas that interest us as we grow the program.

A huge thanks to Sarah Jacobus, Adam Bacchus, Ankur Chakraborty, Eduardo’ Vela” <Nava>, Jay Cox, and Nic Watson.
